SKU : 6013
BURKERT TYPE 6013 - Plunger valve 2/2 way direct-acting
หมวดหมู่ : Process & Control Valves ,  Valve ater and other neutral media ,  Brand ,  Burkert ,
แบรนด์ : BURKERT
Share
คำอธิบาย
วาล์ว 6013 เป็นวาล์วดีไซด์แบบไดเรควาล์ว ชนิดของ Stopper และ Plunger Guide Tube จะถูกเชื่อมเข้าด้วยเพื่อทนแรงดันและป้องกันการรั่วได้ มีซีลให้เลือกหลายชนิดตามงาน มีทั้งแบบ Flange เพื่อยึดแบบ Subbase ได้หลายตัว คอยล์มีให้เลือกทั้ง Polyamide และ Epoxy รวมทั้งคอยล์แบบพิเศษ เพื่อประหยัดไฟ (Pulse coils and 'Kick and Drop' electronics) มีแบบมี Manual (เพื่อการทดสอบ) ให้เลือก วาล์วมี Plug ให้พร้อม (DIN EN 1730-803 FORM A) วาล์วดีไซด์ด้วย Protection Class IP65. และสเตนเลสสตีล (NEMA 4X)
ไดเรคแอคติ้งและคอมแพควาล์ว มี ORIFICE โต 6.0 มม.
มีระบบป้องกันคอยล์หลุดเลื่อนจากการสั่นสะเทือน
ป้องกันการรั่ว โดยการเชื่อม Plunger guide tube
มีคอยล์แบบป้องกันการระเบิดให้เลือก (Explosion Proof Coil)
มีระบบคอยล์ที่มีประหยัดไฟให้เลือก
* สำหรับการเลือกผลิตภัณฑ์ที่ถูกต้องโปรดดูข้อมูลทางเทคนิคภาพและโน้ตเพื่อการใช้งานที่เหมาะสมตามข้อมูล
Description
Valve 6013 is a direct-acting plunger valve. The stopper and plunger guide tube are welded together to enhance pressure resistance and leak-tightness. Various seal material combinations are available depending on the application. A Bürkert-specific flange design (SFB) enables space-saving arrangement of valves on a manifold. The coils are moulded with polyamide or with chemically resistant epoxy. Pulse coils and 'Kick and Drop' electronics are available for overexcitation (plug 2511) for the reduction of electrical power consumption during operation. Optional manual actuation enables quick commissioning and easy maintenance. In combination with a plug in accordance with DIN EN 17301-803 Form A, the valves satisfy protection class IP65. Stainless steel valves satisfy NEMA 4X.
Direct-acting and compact valve up to diameter of DN 6.0
Vibration-proof, bolted coil system
Increased leak-tightness with welded plunger guide tube
Explosion proof versions
Energy-saving pulse versions
* For selecting the correct product please refer to the technical data, images and notes for proper use according to the data sheet.
Can be combined with
Downloads :
Data Sheets : Type 6013
Type 6013 data sheet | direct-acting plunger valve
Data Sheets : Combined with Products
Type 1078 data sheet | digital control with 4 switching functions
Type 2508 data sheet | cable plug according to DIN EN 175301-803
