AIRTEC Series 84-4HF and 84-4HR

คุณสมบัติสินค้า:

SKU : Series 84-4HF and 84-4HR

AIRTEC Series 84-4HF and 84-4HR | manually operated valves hand lever operated 5/2-way and 5/3-way, G1/8, G1/4 and G1/2

Share

หมวดหมู่ : Pneumatic Valves Pneumatic Operated Valves Brand Airtec

แบรนด์ : AIRTEC

Share

Mechanically operated valves

They’re robust, they have long working-lives and they come in a broad range of dimensions and models – AIRTEC’s mechanical and manually operated valves are known for their quality and are used in all sorts of industries. Variations of our standard offerings include our stainless-steel model and our special AIRNOX-coated model. It’s features like these that make AIRTEC components the top performers in extreme production environments.

AIRTEC Series 84-4HF and 84-4HR | manually operated valves hand lever operated 5/2-way and 5/3-way, G1/8, G1/4 and G1/2

Technical details

Temperature range0 ... 8 bar
Operating pressure0°C ... +60°C
MediumFiltered, oil-free and dried compressed air according to ISO 8573-1:2010, Class 7:2:4, instrument air, free of aggressive additives. Alternatively the pressure dew point must be at least 10°C below lowest occurring ambient temperature.
MaterialsBody: Al (anodized), plastic, seals: NBR , inner parts: Al, steel

Hand lever operated spool valve.

5/2-way-Valves

84-4HF-xx-510 5/2-way, hand lever, mechanical spring return
84-4HR-xx-520 5/2-way, two positions, hand lever, detent

Please complete:

  • xx = 18 for G1/8
  • xx = 14 for G1/4
  • xx = 12 for G1/2
5/3-way-Valves
 84-4HF-xx-530 5/3-way, center position closed, hand lever, spring return
 84-4HF-xx-533 5/3-way, center position exhausted, hand lever, spring return
 84-4HR-xx-530 5/3-way, center position closed, hand lever, detent
 84-4HR-xx-533 5/3-way, center position exhausted, hand lever, detent



Technical data


Model-no.:84-4HF-18-51084-4HF-14-51084-4HF-14-53084-4HF-14-533
ConnectionG1/8G1/4G1/4G1/4
Nominal size (mm)4.5655
Flow rate (Nl/min)7501350980980
Weight (kg)0.1680.2520.3100.310

Model-no.:84-4HR-18-52084-4HR-14-52084-4HR-12-52084-4HR-14-53084-4HR-14-53384-4HR-12-530
ConnectionG1/8G1/4G1/2G1/4G1/4G1/2
Nominal size (mm)4.568556.5
Flow rate (Nl/min)750135025009809801600
Weight (kg)0.1700.2550.5400.2500.2500.560



Dimensions



Model-no.:ABCDØ EØ FGHILMSW
84-4HF-18-510

35

2220214.31516903881.31822
84-4HF-14-510402724274.320209348100.522.527
84-4HF-14-530402724274.320209357119.522.527
84-4HF-14-533402724274.320209357119.522.527
84-4HR-18-520352220214.31516903881.31827
84-4HR-14-520402724274.320209348100.522.527
84-4HR-14-530402724274.320209348100.522.527
84-4HR-14-533402724274.320209348100.522.527
84-4HR-12-520503428355.52228103.557128.531.5-
84-4HR-12-530503428355.52230108.557128.531.527

ต้องการ : Data Sheet สินค้า กรุณา แอดไลน์ @flutech.co.th แล้วแจ้งรุ่นที่ต้องการ
