The 55.000 - 56000 serie came up to answer the most estreme demands of pneumatic automation. It is a line in technopolymer , lighter and more compact which offers to demanding customers high performances.
Wide Range ø 2 - 14 mm.
Component Parts and Materials
1. Nickel-plated brass Body
2. Acetalic resin Collet
3. Nickel-plated brass Capsule
4. Steel AISI 301 Clamping washer
5. Technopolymeric positioning ring
6. NBR Molded seal
7. NBR Thread packing
8. Base Threaded Nickel Plated Brass
9. Technopolymeric Body PA
10. NBR seal
- 0.99 bar (-0.099 MPa)
20 bar (2.0 MPa)
- 20 °C
+ 80 °C
Compressed air /
Vacuum / Water
Plastic tubes: PA6, PA11, PA12, Polyethylene, *Polyurethane, PTFE, FEP. *For Polyurethane hoses it is required a minimum hardness of 98 shore.
“UNIVERSAL SHORT” Tapered thread.
Tapered gas in conformity with ISO7.1, BS 21, DIN 2999.
Parallel gas in conformity with ISO 228 Class A.
Metric in conformity with ISO R/262.
The “UNIVERSAL SHORT” taper thread has been designed to offer the following advantages to the users:
• reduced overall lenght;
• smaller hex dimensions compared to the parallel threads;
• to allow the assembly with different female threads both taper as well as parallel.
|To ensure the right tightening also with surfaces not perfectly flat, without spot-facing, concave convex and with different kinds of chamfers or radius.|
|MEASURE||RECOMMENDED TORQUE Nm||BREAKING TORQUE Nm||MEASURE||RECOMMENDED MINIMUM TORQUE Nm||RECOMMENDED MAX TORQUE Nm|
